Baumgartner 866 (QG)

Description

The BFG Caliber 866 is simple pin lever movement, which at least uses a yoke winding system. It has got no shock protection.

This movement is also available without date indication, using the same caliber number.

**Hint:** The jewel count, the types of balances used, and the shock protections employed refer only to the specimens held in the archive and are therefore not relevant for the precise identification of the movement.
Manufacturer:	Baumgartner
Caliber:	866 (QG)
Caliber base:	Baumgartner 866
Size:	12'''
A/h:	18000
lift angle:	44°
Number of jewels:	1
Escapement:	Pin lever
Balance types:	Nickel anular balance
Shock protection(s):	none
Balance bearing / direction hairspring:	Counterclockwise
Moveable stud:	no
Adjust mechanism:	Hairspring key
Construction:	lever escape wheel, seconds wheel, third wheel, center second pinion, mainspring barrel
Winding mechanism:	yoke winding system
Features:	SCI (indirect center seconds) QG (date indication (aperture))
References:	Flume: 1962 23
